In the field of domestic chip processing, JUKI placement machine accounts for about 40% of the use of the quantity, whether it is the advantages of service and use of operation, or the price of JUKI placement machine, have an absolute advantage.Smt Machine
Advantages of JUKI SMT machine:
JUKI placement machine X axis and Y axis control: displacement size organic body magnetic tape and servo motor full closed-loop control, JUKI placement resolution of 2.0um can maintain permanent high precision; not affected by dust, temperature, to achieve high-precision positioning; The JUKI placement machine is driven simultaneously with the Y-axis motor.
JUKI placement machine identification mode: laser and CAMERA recognition, small components are directly identified by laser, special-shaped components are identified by camera, high-speed and accurate; The laser can identify the height of the components, and the longitudinal identification method will not affect the mounting quality due to the wear and whitish of the nozzle or other stolen goods; After the working head absorbs the component, it is directly moved to the mounting target and misjudged into the component, causing the leakage of the component; Laser identification of component height, AC master motor can automatically control the mounting height and force, put an end to the components in the placement cracking, while reducing the nozzle impact force and friction, prolong the service life of the nozzle,
JUKI SMT working head: one working head four thieves, while sucking easy points; Each small head of the Z axis has a motor driven individually, which can control the mounting force, the suction nozzle is not easy to break, and there is no need for maintenance; θ shaft each small head has a motor driven separately, not affected by the change of the angle of the patch, can ensure the accuracy of the mounting angle, when a motor has a problem, the other heads can work normally.
JUKI placement machine mounting method: the use of vacuum pressure to destroy the timing of the self-calibration function, to prevent the component from being brought back at the moment of the placement, high-density placement will not affect the next component;
JUKI SMT feeder: there are four support points fixed, which enhances the stability and reliability of the feeder positioning; The feeder action is driven by a separate mechanical structure; The working head automatically measures the suction height of the components, ensuring the suction reliability of surprise components such as 0402 and 0201.
Advantages of JUKI SMT Machine:
Inexpensive: JUKI SMT reduces functionality to the required Z low limit, ensuring high productivity and achieving small and lightweight at a lower cost. The new Z laser identification system is the same as the Z advanced model.
High versatility: JUKI placement machine models are mostly different types of different use advantages, the machine has a dedicated type and multi-functional, the specific type will be relatively fast in the production speed, because he is limited to the production of one. In order to meet the orders of many enterprises scattered customers, they have launched a multi-functional machine to meet the needs of enterprises for the use of placement machines.
Simple operation: The advantage of the JUKI brand Z is that its operation is simple, many placement machines have more complex lines and structures, but the structure of their placement machines is very simple.
