Vacuum material:
1, tungsten steel suction nozzle: tungsten steel suction mouth is strong, used, but easy to hair white, white with oil pen, but also can continue to use.
2, ceramic suction mouth: ceramic suction mouth never hair white, but very crisp, easy to crack.Be careful to prevent or reduce cracking.
3, diamond steel suction mouth: robust, easy to use, never hair white, but very expensive, is not cost-effective.
4, glue head suction mouth: when the appearance of the material is not smooth or the material is sticky, suitable to choose the nozzle, but the nozzle mouth life is not long, it is recommended to set the nozzle suction mouth, buy more glue mouth head standby, when the mouth is worn, can directly change the mouth head.
Vacuum size:
Standard specifications of material, suction specifications are fixed, when some materials are not small, shape is strange strange, need to make suction nozzle.Shape of suction mouth:
Suction mouth shape has a square hole, YTO, V groove, etc.The suction nozzle, generally according to the shape of the material, select a flat suction point, some made of elongated suction nozzle, the groove plane absorption, some according to the margin of the material, made into the shape, some two ends with the plane, the center is uneven instead, to build a bridge.Some materials have sticky, not easy to put materials, you want to open some groove in the suction mouth wall, or make glue head.
