Many beginners for SMT patch machine processing skills do not meet the understanding and use, in fact, our domestic SMT patch machine system is easy to understand language programming, relative to imported patch machine is more convenient, perhaps we's understand the mount industry homework, now let's understand the SMT patch machine processing process.
One, generally in the front of the line we can use automatic or semi-automatic tin paste mixer stir tin paste, can also use artificial mixing, and then through the track to the automatic or semi-automatic wire printing machine, from the assembly line to the designated PCB board and then finish a paste front operation, and then uniform tin paste samples to the SMT patch machine.
Second, after the PCB board came to SMT patch machine, we can formally processing mount operation, usually we need to use multifunctional patch machine for a job task, we can also choose different speed and type of machine, after we set in the system management software after nozzle will be the original on the PCB board to the return welding operation.Three, when the PCB board into the reflux welding area, usually different reflux welding machine has multiple temperature zone, generally three, six, three different varieties, temperature, we choose the appropriate temperature, and then let the element can firmly on the PCB board so the whole production process is finished, then will produce good PCB board to AOI detection system of SMT patch mount effect, if detected a problem, from the new, if no problem, to end the task.
